Crestron
Studio®
1.81 – December 22, 2020
Product or Content Description
Crestron Studio® is Crestron's advanced programming
application with the following features:
·
Source
Routes diagram to allow the design of the AV routing in 3-series systems
·
Generates
fully programmed touch screens for
Residential/Presentation/Education/Commercial environments, including Crestron
Fusion® integration.
·
Screen
Designers for Smart Graphics projects and for MLX-3 type list-based screens
·
Screen
Designer/Programming Designer integration.\
·
Ability
to import Smart Graphics™ VTPro projects.
·
Custom
Macro style programming dialog for events, keypads, touch screens. Includes
global macros, variable editor, scheduler, as well as assigning device
commands, conditionals, delays, etc. Visual callout programming dialog in Touch
Screen Designer.
·
Automated
page and program generation if desired, with touch screen pages completely
redesigned and based on Smart Graphics
·
Programming
Designer full functionality, with ability to import SIMPL Windows™ programs
·
Finish
View: Build, upload, Network Setup Wizard.
·
Ability
to combine generated programs and SIMPL programs
·
Full
content of Device and Crestron databases is imported and available.
·
Faceplate
Designer
The following sections are
available in the release notes:
·
System Requirements and Dependencies
·
Operational Installation/ Upgrade Instructions
·
Version History New Features and Changes
·
Bug Fixes
·
Known Issues
System Requirements and Dependencies
Software Requirements:
· Toolbox
version 2.38.880.00 or later
· Smart Graphics™
Controls version 2.12.05 or later
Supported Operating Systems:
·
Windows™
v7, 32 or 64-bit platforms supported when installed and run on an account with administrative
privileges and XP Compatibility mode turned OFF. We recommend 64-bit platforms
because additional memory is available to the Crestron Studio application.
DirectX™ 9 must be supported by the video drivers.
·
Windows™
8.1.
·
Windows™
10.
·
Has
been tested running on VMWare™ virtual machines.
·
Has
been tested running on Parallels™
Recommended
PC Configuration:
·
i7
processor with 8GB RAM
·
Solid
state drive
Operational
Installation/Upgrade Instructions
Recommended upgrade steps are:
· Download Crestron Studio from the Crestron website
· Double click on the file
· Follow the prompts
Note:
If upgrading from a previous version of Crestron Studio to version 1.7.6, the first time Crestron Studio is run it will take approximately five minutes for drivers to be downloaded. Monitor the download status on the title bar at the top right of the application.
Version History
Version 1.81 December 22, 2020
Changes Since Last Version
New Features and Changes
·
Replaces
internal Adobe Flash component with Harman Flash to address end of life for
Adobe Flash. With this change the user will still be able to use Crestron Studio to create Smart Graphics
projects even though Adobe Flash is not installed on the computer.
·
Added
engraving support for Cameo devices
·
Increased engraving font size from 7.45 to 8.5 points for Crestron
Transport and Crestron Transport Outline fonts on Horizon devices. The font
size will remain the same on existing engravings. New engravings will use the
larger font size. Take care when modifying engravings generated with previous
versions to ensure the transport font size is what you intend.
·
Address
bug where Crestron Studio Certified Drivers got stuck
on downloading.
Version 1.77 July 25, 2019
Changes Since Last Version
New
Features and Changes
·
Added
support for the following devices
o AM-200 & AM-300
o HD-MD-300-c
o DM-TX-4K-100c
·
Added
support for Run As functionality
·
Added
support for “Campus Room Solutions” for Campus Room Solutions projects
o Please see Crestron Studio
Help topic for documentation
·
Data
package with support for SSW-EL & SSC-EL will follow shortly and requires
Crestron Studio v1.77
Version 1.76 January 31, 2019
New
Features and Changes
·
Sonos Update
·
Support
for SSC and SSW Status Sign engravings
·
Certified
Driver support
·
HR-310
Engraving Support in a System Project
·
TV
Presets V2 support added
Version 1.75
New Features and
Changes
·
Added Horizon Keypad support
·
Significant improvements to the Engraver designer for the
following devices, including Symbol Fonts & Sans Pro on select models:
·
HZ-KPCN
·
MPC3-201
·
MPC3-302
·
Note: Engraving for HR-310 is not yet available in Studio but, will
be in the future with a data package update.
The
following new devices are now included (without requiring separate device
packages):
·
DM-NVX-35x (Transmitter)
·
DM-NVX-35xC (Receiver)
·
DM-NVX-35xC (Transmitter)
·
DM-NVX-35x (Receiver)
·
HZ-KPCN
·
MPC3-201
·
MPC3-302
·
TSR-310
Version 1.71
New Features and
Changes
·
Join
Now & Reserve Now pages add to commercial systems
·
Added
support for NVX product line (need separate data package to enable these
devices)
·
Added
support for HR-310
·
Fusion
updates to match the SSI Fusion standards
·
Note:
If you have used Heos 7.0 modules in previous
versions, you must remove and re-add 7.1 modules to avoid compile errors
·
The
following new devices are now included:
o HR-310
o DIN-CENCN-2(-POE)
o CSA-PWS10S-HUB-ENET
o GLS-OIRLCL-C-CN
o CSM-QMTDC-HSHEER-CN
o CSM-QMTDC-HSHEER-EX
Version 1.70
New Features and
Changes
·
Updated
templates to match the latest Mercury and AV Framework UX
·
Source
Routes Updates:
·
Improved
multi-display template support
·
Improved
AV Framework template programming model
·
Added
support for PinPoint UX
·
Added
No-touch source switching behavior
·
Source
Routes- Added Auto-Layout feature
·
Source
Routes- Added Hide/Show unused connections feature
·
The
following new devices are now included:
o DMPS3-4K-200-C
o PC-200
o PC-300
o CHV-TSTAT-FCU
o Status Sign
o DMPS3-4K-300-C
o AMP-8075
o AMP-8150
· Source Routes Updates:
·
DMPS3-4K-200-C
·
DMPS3-4K-200-C
·
DMPS3-4K-300-C
·
HD-MD-400-C-E
·
HD-MD4X1-4K-E
·
HD-MD4X2-4K-E
·
HD-MD6X2-4K-E
Version 1.61
New Features and
Changes
·
Added template support
for the TSW-560-P
·
Automatic programming
of HR-100 and HR-150 remotes in Presentation systems.
·
Updated DMPS-4K-150-C
module to expose macro programming commands: DM_Output_Disabled/Enabled
and HDMI_Output_Disabled/Enabled
Version 1.60
New Features and
Changes
·
Added support for Sonos.
·
Automatic programming
of HR-100 and HR-150 remotes.
·
Many user experience
updates made to the Home touch screen templates. This includes new background
images, updated source selection experience, streamlined DVR pages, and more.
·
Updated TSR-302
programming model to make it easier to program off of
the currently selected source.
·
Improved the TSR-302
user experience with improved graphics as well as hard-buttons that target the
selected source.
·
Added support for TV
Presets.
·
Many speed
improvements in the Touch Screen Designer.
·
Added custom button
labeling support for the HR-100 and HR-150 remotes.
·
Programming Editor -
Added an easy way to enable programmable properties without requiring a switch
over to the property grid and manually assigning a join number.
·
The
following new devices/drivers are now included:
·
AM-101
·
Autonomic
MMS-1e
·
CAEN-BLOCK-CENCN-2-POE
·
CLX-2DIMFLV8
·
CLX-2DIMU8
·
CLW-DIMFLVEX-P
·
DSP-1282
·
DSP1283
·
Sonos Connect
·
TSW-560
·
TSW-760
·
TSW-1060
·
Yale
Locks YRD216 PBDB
·
Yale
Locks YRD226-246-TSDB
·
ComcastXR11.ir
·
Arris
XG1v3 – AX013ANM(C)
·
Arris
XG1v1 – MX011ANM(C)
·
Pace
XG1v3 – PX013ANM(C)
·
Pace
XG1v1 – PX001ANM(C)
·
Samsung
XG2 – SX022ANM(C)
·
Pace
XG2 – PX022ANM(C)
·
Pace
Xi3 – PX032ANI
·
Pace
XiD – PXD01ANI
·
Cisco
XiD – CXD01ANI
·
Rackmount
– AX11RANM
·
DirecTV_HR25-100.ir
·
TiVo
Series 3 HD v1.1
·
Onkyo TX-RZ810 IP v1.0
·
Onkyo TX-RZ810 v1.0
·
Onkyo TX-NR757 IP and Serial
·
Onkyo TX-RZ710 IP and Serial
·
Onkyo TX-RZ810 IP and Serial
·
Onkyo TX-RZ1100 IP and Serial
·
Onkyo TX-RZ3100 IP and Serial
·
Onkyo PR-RZ5100 IP and Serial
·
Integra
DRX-5 IP v1.0
·
Integra
DRX-5 v1.0
·
Integra
DRX-4 IP and Serial
·
Integra
DRX-5 IP and Serial
·
Integra
DRX-7 IP and Serial
·
Integra
DRX-R1 IP and Serial
·
Integra
DRC-R1 IP and Serial
·
Denon
AVR-X5200W IP v1.0
·
Denon
AVR-X5200W v1.0
·
Denon
S700W IP and Serial
·
Denon
S900W IP and Serial
·
Denon
AVR-X1100W IP and Serial
·
Denon
AVR-X2100W IP and Serial
·
Denon
AVR-X3100W IP and Serial
·
Denon
AVR-X4100W IP and Serial
·
Denon
AVR-X5200W IP and Serial
·
Marantz
AV7702 IP v1.0
·
Marantz
AV7702 v1.0
·
Marantz
AV7702 IP and Serial
·
Marantz
SR7009 IP and Serial
Version 1.50
New Features and Changes
·
Added
Undo to the Touch Screen Designer.
·
Supports
the Crestron DSP product line.
·
Inline
editing of existing command steps in the Macro Editor.
·
Notifications
will be shown inside of Studio when new devices are available.
·
MP-B10\MP-B20
default programming automatically added.
·
TT-1xx
default programming automatically added.
·
Pyng
Trigger and Listen modules automatically included when adding a Pyng Hub.
·
Improved
memory management.
·
Various
improvements to Source Routes.
·
Added
exclusive OR to expressions and conditionals.
·
Alt+C in the macro editor to comment out/in the step.
·
The
following new devices are now included:
·
AM-101
·
C2N-LCDB3
·
CEN-GWEXER
·
CLC-FANDELVEX
·
CSA-PWS10S-HUB-E
·
CSM-QMTDC-275-4-EX
·
DM-DGE-200-C
·
DSP-860
·
DSP-1280
·
HD-MD4X1-4K-E
·
HD-MD4X2-4K-E
·
HD-MD6X2-4K-E
·
HD-MD-400-C-E
·
TS-1542-C
·
The following new
templates are now included:
·
TST-602
·
TS-1542
·
FT-TSC600
Version 1.41
New Features and Changes
·
The following new
devices are now included:
·
DMPS3-4K-100-C
·
DMPS3-4K-50
·
DMPS3-300-C-AEC
Version 1.40
New Features and Changes
·
Studio now creates
systems for 3-series processors only
o If you have previously created Studio systems
with a 2-series processor, then you will need to use Studio 1.38
·
Touchscreen Linking.
See help file for details.
·
Added support for
codecs
·
Added local variable
support
·
New Touchscreen
Designer Design Explorer
·
Added support for
combined ER\EX gateways
·
Expression feedback
includes analogs and serials now
·
Added subpage reference
list support
Version 1.38
New Features and
Changes
·
Compatibility changes
to support Adobe Flash Player changes
·
Compatibility changes
to support Smart Graphics 1.8
Version 1.37
New Features and
Changes
·
Includes easy
integration with CEC devices
·
The following new
devices for Presentation Systems are now included:
o DMPS3-4K-150-C
o DM-MD8X1-4K-C
o HD-MD8x1-4K
·
One button to both
build and upload.
·
Includes faceplates
for HTT-B10EX and CLW-SLV-P
·
Touch Screen Designer
Smart Graphics Control Gallery scrolling is much faster now
·
Copy and paste touch
screen elements includes programming
Version 1.35
New Features and
Changes
Generates Presentation systems
·
This includes a new
template for Presentation/Education/Commercial environments
Tight Crestron Fusion® integration
·
When Presentation
systems are created, Crestron Fusion® features will automatically be applied
·
Sends display usage
status
·
Sends selected source
usage statistics to Crestron Fusion® for usage reporting
·
Automatically connects
to Crestron occupancy sensors
·
Sends offline
notification to Crestron Fusion® if a Crestron device goes offline
·
Help Desk Interface
from touch screens
o From the Product Browser, simply add “Fusion
Help Desk” and the logic and pages will be built automatically.
Navigation bar in SystemDesigner is now collapsible to save screen real-estate
Version 1.32
New Features and
Changes
·
Generates touch screen
layouts and programming for additional Smart Graphics UIs, including MLX-3 and
Crestron App templates (both for Tablets and for Phones)
·
This includes a new
template for Presentation/Education/Commercial environments
·
Basic Pyng Integration
·
Selection, per touch
screen, for visible Rooms and Sources
·
Source Routes - Continued
refinement and additional device support
·
Improved speed
·
Improved memory
management Touch Screen designer includes the ability to show join numbers and
click assign of all join types
·
Language culture
locked to English, to prevent issues in non-English versions of Windows.
·
Totally new Smart
Graphics pages and custom modules for a system composed of Media Zones and
Lighting Zones. Zones may only be used on 3-Series control systems.
·
Automatic page and
program generation.
·
Pages can be modified
manually after generation.
·
Visual page generation
without programming can be done in manual systems
·
Page Generation
Assistant is available to enable precise control of page generation
·
Page templates are for
Smart Graphics touch screens and MLX-3.
·
Source Routing View:
Specify audio/video paths through system. Switching will automatically
configure the devices.
·
Added support for
HR-100, HR-150, and TSR-302.
·
NOTE: As of this
release HR-100 and HR-150 buttons will not have programming automatically
assigned, but through the macro editor you can assign programming to each
button.
·
Added Device Designer
to allow definition of a device separately from a module.
Bugs Fixed
Bugs
Fixed for 1.76:
·
Addressed
a variety of stability issues
Bugs
Fixed for 1.70:
·
Fixed
issue related to importing .vtz files
·
Made
a variety of stability improvements
·
Avoids
a crash when the Flex SDK is missing
·
Made
Pyng trigger and listen modules available from the
Product Browser
·
Corrected
an issue with Media Player application not always connecting correct to the
CEN-NSP1
·
Made
a variety of fixes related to codec integration
·
Fixed
issue with importing Engraver files
·
Corrected
EISC signal display in Advanced Programming
·
Added
TSW-x60 faceplates to Touch Screen Designer
·
Corrected
a variety of program generation and compilation crashes
·
Allows
2-series processors as remote processors
·
Updated
Sonos modules
Bugs
Fixed for 1.61.011:
·
Addressed
a TV Preset related Program generation issue that could make program generation
times be extremely long.
·
Addressed
an issue in the Touch Screen Designer that could cause a crash on renaming a
page.]
·
Addressed
a case where deletion of a touch screen could take an excessive amount of time.
·
Addressed
issue where program generation could fail with systems that contain a large number of DVRs.
Bugs
Fixed for 1.60.131:
·
Addressed
a scheduler issue where the day of the week selection would get lost when clicking
another scheduled event.
·
Addressed
a variety of template related issues.
·
Addressed
a variety of stability issues and memory leaks.
·
Addressed
issues where macro programming RSD steps would not update correctly in the
Programming Editor.
·
Corrected
a variety of issues related to the wait cursor.
·
Improved
touchscreen build performance on Windows 10 machines.
·
Addressed
a variety of issues related to replacing devices.
·
Corrected
missing Media Manager page warning.
Bugs
Fixed for 1.50.222:
·
Addressed
a variety of RL2 related issues
·
Addressed
issues in Touch Screen Designer that could cause a crash when expanding the
Icon property
·
Addressed
issues related to copying and pasting subpage references
·
Correctly
hiding [~BeginGroup~] [~EndGroup~]
signals from macro editor
·
Addressed
a variety of stability issues related to the file system and SQL
Bugs
Fixed for 1.41.004:
·
Addressed
a variety of DMPS-3x template issues
·
DMPS3-4K-150-C,
DMPS3-200-C and DM-MD8X1-4K-C module fixes
·
Addressed
a variety of codec related items
·
Corrected
replace device issue that could have resulted in a, "JoinSignal
has unmatched PanelElement" error
·
Addressed
a variety of stability issues introduced in 1.40
·
Addressed
issue importing smw files that contains
.ceds
Bugs Fixed for 1.40.370:
·
Addressed
a variety of stability issues
·
Various
faceplates added
·
DM
addressing and connection issues addressed
·
Corrected
volume control timeout issue on SWAMPE zones
·
Addressed
a variety of issues related to digital inputs
·
Corrected
copy and paste issues in the Touch Screen Designer
·
Corrected
a variety of device modeling issues on the Source Routes view
·
Corrected
a few more SQL related install issues
Bugs
Fixed for 1.38.009:
·
Addressed
compatibility issue when updating to Adobe Flash Player v20.0.0267 (and potentially
later versions)
Bugs
Fixed for 1.38.007:
·
Addressed
a potential lock-up during compile on Windows 10 machines
Bugs
Fixed for 1.38.005:
·
Compatibility
changes to support Smart Graphics 1.8
Bugs
Fixed for 1.37.015:
·
Addressed
an install issue related to SQL Express
Bugs
Fixed for 1.37.014:
·
Addressed
multiple exceptions
·
Cleaned
up a few visual items in the templates
Bugs
Fixed for 1.35.005:
·
Addressed
multiple exceptions
·
Addressed
issues related to connecting to SQL Express
·
Update
templates to include all Pyng subsystems
Known Issues
Crestron Studio®
·
Known
issue for v1.76
There is a known issue when creating an engraving in an upgraded project (created prior to 1.76),
and the engravable device had no prior engraving data. The user should either
delete and re-add the device or create new engravings in an Engravings project.
This applies to MPC3-201, MPC3-302, HZ-KPCN, and HR-310.
·
If
you are running 64-bit Windows™ versions, about twice as much memory is now
available to the application for use. There are warnings that will caution you
when memory usage is getting too high, so that you may take precautions like
closing Designers and saving your program.
·
You
must run as administrator for now, due to some issues with the Microsoft
signing dll, capicom.dll.
·
Studio
cannot install on some PCs that enable the security setting "System
Cryptography".\
·
Installs
under Windows™ 8.1 may not succeed the first time. Wait for .NET Framework™ and
SQL to finish installing - they are initiated by our install. Then run our
install again.
·
Devices
not yet supported with modules: DM-MD64x64, and DMC-VID4.
Program Designer
·
SIMPL+
Editor keystrokes show a noticeable delay when Touch Screen Designer is open,
and to a much lesser extent if other designers are open. For optimal
performance, close Touch Screen Designer, or for even better performance,
restart Crestron Studio and run only the SIMPL+™ Editor.
Theme Editor
·
Turn
off restore points when working with the Theme Editor.
TSR-310 Template
·
On
Cable box/DVR pages, depending on the capabilities of the box, if there are no
advanced commands, you may need to delete the overflow button. Otherwise, there
will be a button on the UI that does nothing. That is the button with the icon,
"..." .
·
On
Blu-ray related pages, depending on the model, most functions are handled via
the hard buttons. However, if there are remaining commands on the screen you
may need to manually align the remaining buttons or if they are commands not
used by the user then simply delete those soft buttons.
Notes on current system
limitations for automatic program generation
Receivers and displays are limited to the following rules:
·
Only 1 zone/output is
supported.
·
Breakaway of audio and
video signals is not supported.
·
No device feedback is
supported; commands will only be sent from the program to the device.
·
The device should be
off when the program starts in order to remain
synchronized.
·
The following triggers
are available from the program to the device: Power On, Power Off, Power Off
Confirmation, Volume Up, Volume Down, Mute Toggle, Input selection (10
different inputs)
·
"Do not disturb" has no effect.
·
Media module commands, feedback items, and
parameters may have missing or inaccurate descriptions.
Licensing and Copyright Information
Certain Crestron products contain open source software. For
specific information, please visit www.crestron.com/opensource
Trademarks:
·
SQL
Express, DirectX, .NET Framework, Windows 7, Windows 8.1, and Windows 10 are
trademarks of Microsoft Corporation.
·
VMWare
is a trademark of VMWare Inc.
·
Parallels
is a trademark of Parallels IP Holdings GmbH.
·
Crestron
Studio, Crestron App, SIMPL Windows, VTPro, SystemBuilder,
and D3 Pro are trademarks of Crestron Electronics Inc.
